The principle of structure

Capacitive target flowmeter is based on the traditional target flowmeter, with the development of new sensors, microelectronics technology research and development into a new type of capacitance induction flowmeter, it has both orifice plate, the characteristics of vortex flowmeter, such as no moving parts, and also has a high sensitivity, and volumetric flowmeter accuracy of near beauty, span a wide range. The chip-level capacitive force sensor and efficient anti-overload structure design are the key core of this new product to achieve high precision and high stability. In addition to its unique anti-interference and anti-impurity performance, it can replace the flow measurement problem which can be measured by conventional flow. Especially in high viscosity, dirty medium, easy coagulation and easy blocking, high temperature, low temperature, strong corrosion and other difficult flow measurement conditions with good adaptability.

The product application

Widely used in petroleum, chemical, metallurgy, electric power, pharmaceutical, environmental protection, food and other fields. - Wide range of pipe diameter: Φ10~Φ2000 to larger; - Wide temperature range: -200°C ~ 700°C; - High/low pressure working condition: 0~42MPa; - Gas, liquid (high viscosity liquid, slurry), steam; - Low flow velocity medium with a minimum measurable flow rate of 0.08m/s.

Product features

◆ The whole instrument structure is strong without moving parts, easy to disassemble

◆ Can choose a variety of anti-corrosion and high and low temperature resistant materials (such as Hastelloy, titanium, etc.)

◆ The whole machine can be sealed without dead Angle (welding form), without any leakage point, can withstand 42MPa high pressure

◆ The pressure loss is small, only about 1/2△P of the standard hole plate

◆ Anti-interference, anti-impurity ability is very strong

◆ The instrument is equipped with self-checking procedure, the fault phenomenon at a glance

◆ The sensor does not contact with the measured medium, there is no wear of parts, safe and reliable use

◆ Dry calibration method can be used on the spot, that is, using weights

Single key operation can complete the calibration

◆ With a variety of installation methods for choice, such as the choice of online insertion, low installation cost

With integrated temperature and pressure compensation, direct output quality or standard

◆ With optional small signal excision, nonlinear correction, filter time optional

Can accurately measure all kinds of normal temperature, high temperature 500 degrees, low temperature -200 degrees under the condition of gas body, liquid flow

◆ Accurate measurement, precision can reach 0.2%

◆ Good repeatability, generally 0.05% ~ 0.08%, fast measurement

◆ The range can be changed according to the actual need to replace the stopper (target)

Low power battery field display, online direct reading value, the display can read instantaneous and cumulative flow and percentage bar chart at the same time, easy to install, easy to maintain

◆ A variety of output forms, can be far all kinds of parameters

◆ Strong earthquake resistance, pulsating flow can be measured within a certain range
