Flow model: liquid 3m/s; gas 100m/s

Temperature: -20. .80°C

Applicable media: water: ethylene glycol solution: air:

Oil (low viscosity oil: ≤

40mm? /S (40°C) High viscosity oil: >40mmm- /s (40C)

Signal output: switching capacity PNP/NPV. S1 (flow protection), S2 (temperature protection)

Analog 0/4...20mA, 0/1...5V/10V (flow/temperature)

Power supply: 24V 20% DC

On current: up to 400mA (PNP or NPN type)

Current loss: <100m4

Flow indicator:

Four-bit L is the digital tube.

Setup method: key setting

Pressure-resistant country: 100bar

Temperature gradient: ≤4° C/S

Response time:

1-13s, typical value 2s

Initialization time: about 8s

Electrical protection: reverse phase, short circuit, overload protection

Protection level: IP6T

Media temperature: -20-80°c

Ambient temperature: -20-80°c

Storage temperature:

-20-100°C

Wiring method: M12 connector/direct wire attachment
