Technical parameters

◇ Power supply voltage: 10... 30Vdc

◇ Current consumption: consistent with the output signal current (4... 20 ma)

2 wire current type analog output

Output type: 2 wire 4... 20mA

◇ Load RA (ohm) : RA≤(Us-10)V/0.02A

Linearity: ≤±0.5% range

◇ Sensor: PT100Class A (PT1000 can be customized)

Accuracy: ≤±0.2% range

His temperature

Dielectric temperature

(Measuring fan circumference) : -200... 1800℃ (within this range, defined by the user)

◇ Ambient temperature: -20... 80 ℃

◇ Storage temperature: -30... 100 ℃

His material

Shell: Die cast aluminum

Medium contact part: stainless steel 316

Protection level: IP65

◇ Outlet mode: terminal wiring
